Automated Video Measuring Machine ORT-GAN-2000
  • Features
  • Specification
Precision Equipment      Hardware:
1Marble base, post and worktable, stable, firm framework.
2Marble table. Reducing mechanical assembly error, ensure precision movement of X, Y axes.
3High verticality of X, Y axes can ensure measurement accuracy up to 2.5+L/ 200um. To get high precision even without coordinate detection function.
5Precision Ballscrew transmission make movement fast, flexible and reliable.
6Optical grinded Glass working stage, Z-axis is calibrated to ensure travel direction vertical to glass plane so that the measuring result with high accuracy.
7Programmable laser pen positioning allowed the machine find appropriate position rapidly and work more quick.
8The first one who introduced sub-pixel measurement in video measure industry. Do not need any professional operation   skills for operator, enhance measuring efficiency greatly.
9Automatic Z axis focusing enhanced the precision while refocusing, user need to move X, Y axes only, convenient and quick.
Smart Software      Software
1Multiform output such as DXF,WORD, EXCEL etc. CAD drawing input and comparison function. It can directly measure and calculate straightness, roundness, position, parallelism, inclination, perpendicularity, concentricity, symmetry, and other geometric tolerances.
2Ample geometrical measurement function including drawing, label, edit, operation board measure etc., It provides measurement and drawing functions for  point, line, circle, arc, ellipse, groove, rectangle, closed curve etc.
3SPC key parameters analysis according to the data of report form, automatic calculation of Ca, Cp, Cpk, Max, Min, Range, Avg, Std etc.
4Auto tolerance output and alarm with color, sound and note, especially have product dimension tracking function.
5LED three ring lights on octant top(eight segment) + transparent parallel lights, brightness adjustable
6Fast & automatically focus function. One focusing in one second. Repeatability of focusing at high magnification is<0.01mm, If the focusing time is set to 2 to 3 seconds.
7Can measure the various complex graphics including curves.
8Powerful photograph, montage and virtual measuring function.
9Lasers and probes can be added if needed, so as to complete the three-dimensional size measurement.
Ultra-fast Detection      Detection Efficiency
1Testing product: ≤2000*1500*200mm, suitable for various of production’s inspection
2Fast procession to single product or feature detection
3Fast moving speed of worktable: the fastest moving speed of XY axis is 200mm/s, acceleration can reach 400
4Fast image calculation speed: powerful image calculation processing and calculation capabilities, work does not need to be corrected, coordinate conversion function, high measurement efficiency
Stable Performance      Operations:
1Continuous operation, low failure rate, normal basic maintenance once every 6 months
2Continuous operation with high utilization rate: 7*20H
3Long service life: Imported high-precision component modules are selected to ensure the long-term stability of the equipment
4Good repeatability: the accuracy of the equipment remains unchanged after long-term operation


型 号      Model No外形尺寸(mm)      External Size仪器重量(kg)      Weight(kg)玻璃台承重 Max. load仪器电源     Power supply
ORT-GAN-20003160*2300*15002650kg30kg220V(AC) 50HZ
工作台     Worktable工作台尺寸(mm)      Marble Size1730*2260玻璃台尺寸(mm)      Glass Size1660*2180
运动行程(mm) Travel RangeX:1500mm  Y:2000mm调焦行程(mm)      Travel Range(Z轴)200mm      (Z axis)
光学系统      Vision system高分辨率彩色CCD 1/3〞       High-resolution CCD 1/3 inch
全自动变倍同轴光镜头,倍率:0.7-4.5X     工作距离:88mm      Automatic zoom coaxial lens 0.7-4.5X;  Work-distance:88mm
视频放大倍率:28-180X     显示分辨率:0.0005mm      Video magnification:28-180 X;Display resolution:0.0005mm
专业精准自动测量软件,自动对焦        Accurate  image auto-measuring software
线性精度(um)      Linear AccuracyX、Y线性精度:2.5+L/200 um        Z轴精度;5+L/200 um      (L为被测长度单位:mm)      X,Y Linear Accuracy:2.5+L/200      Z≤5+L/200 um  (L means measured length, unit: mm)
灯源     Illumination可程控白色多角度五环八区四十项环形表面光及平行冷光源,亮度可调      LED  surface ring light in five rings & octant pattern (8 phases) + transparent parallel light, all lights adjustable.
