Precision Laser Cutting Machine ORT-CUT-200
  • Features
  • Specification
Precision Equipment      Hardware:
1Marble base, post and worktable, stable, firm framework.
2Two-tier table structure (patented). Reducing mechanical assembly error, ensure precision movement of X, Y axes.
3Precision Ballscrew transmission make movement fast, flexible and reliable.
4The adsorption platform is supported by a dense array hole grinding platform, which ensures smooth adsorption while ensuring the flatness of the processing.
5High-performance visual inspection module, clear positioning for processing
6Powerful motion control can be matched with imported linear motor to ensure accurate, fast and repeatable motion positioning
Smart Software      ( 3D) Software
1Different layers can set different process parameters to achieve different effects
2Graphic optimization function, curve segmentation (interrupt the curve, specify the position with the mouse)      Smooth curve      Remove duplicate lines      Remove small graphics (input less than ** size)      Merge connected lines      Shred line segments (enter the length or number of line segments)
3The slitting compensation function generates the slitting compensation tool path of the specified parameters for graphics to improve the dimensional accuracy
4Graphic editing functions: move, rotate, mirror, offset, array, etc.
5Drawing functions: straight lines, arcs, rectangles, splines, polygons, etc.
Ultra-fast Detection      Detection Efficiency
1Testing product: Max 200*300*2mm
2Max cutting speed 1m/s, with edge breakage<3mm
3Fast moving speed of worktable: the fastest moving speed of XY axis is 1000mm/s, acceleration can reach 10G
4Fast image calculation speed: powerful image calculation processing and calculation capabilities, high measurement efficiency
Stable Performance      Operation:
1Continuous operation, low failure rate, normal basic maintenance once every 6 months
2Continuous operation with high utilization rate: 7*20H
3Long service life: Imported high-precision component modules are selected to ensure the long-term stability of the equipment
4Good repeatability: the accuracy of the equipment remains unchanged after long-term operation
Model No(mm)      External Size(kgs)      Weight(kgs) Max. load Power supply
ORT-CUT-2001400*1650*18002000kg5kg220V(AC)50HZ/0.8MPa
Vision system     High pixel CCD
  High resolution telecentric lens
Laser systemwave length:1064<15ps(import)
power:10-100W
(um)      Linear Accuracy≤10μm
 Positioning accuracy0.003mm
 Repeated Positioning accuracy0.0015mm
 Cutting speed1m/s
 Laser beam  Single/multiple beam (selectable)
 Min. edge breakage3μm
  Max cutting thickness2mm
 Software   Video+laser software
 vacuum cleaners>8m3/min
