Roller-sifting CG AOI ORT-ROL-6000
  • Features
  • Specification
Precision Equipment      Hardware
1Welded square tube base, post and worktable, stable, firm framework.
2High-precision and high-speed roller conveyor line.
3Automatic centering mechanism to ensure the accuracy of incoming material position;
4Precise magnetic wheel transmission system, non-contact transmission, reduce vibration and improve workpiece conveying accuracy;
5Optimum high-precision drive shaft (straightness≤0.03mm/m), matched with high-precision PEEK rollers (run-out≤0.01mm)
6Environmental cleanliness class1000
7Cleaning equipment, high-precision double-sided laminating equipment, Plusma, labeling / inkjet printer can be configured according to customer needs
Smart Software      ( 3D) Software
1Multiform output such as DXF,WORD, EXCEL etc. CAD drawing input and comparison function. It can directly measure and calculate straightness, roundness, position, parallelism, inclination, perpendicularity, concentricity, symmetry, and other geometric tolerances.
2Ample geometrical measurement function including drawing, label, edit, operation board measure etc., It provides measurement and drawing functions for  point, line, circle, arc, ellipse, groove, rectangle, closed curve etc.
3SPC key parameters analysis according to the data of report form, automatic calculation of Ca, Cp, Cpk, Max, Min, Range, Avg, Std etc.
4Auto tolerance output and alarm with color, sound and note, especially have product dimension tracking function.
7High-brightness combined line light source + high-brightness bar light source + high-brightness arc light source,      the brightness can be adjusted by program control.
5The first one who introduced sub-pixel measurement in video measure industry. Do not need any professional operation   skills for operator, enhance measuring efficiency greatly.
6Powerful photograph, montage and virtual measuring function.
Ultra-fast Detection      Detection Efficiency
1Testing production: 5~15.5” 2D/2.5/3D cover glass(white glass, filmed glass, TP-sensor…)
2Compatible with 2D, 2.5D, 3D products of various specifications and sizes, incoming materials: 8~15.6 inch single-chip flow, 8 inch or less dual-chip flow.
3A Fast procession to single product or feature detection:Testing content: appearance defect detection (foreign objects, stains, screen printing, scratches, chipping, lack of ink, lack of IR holes, etc.)      CT: ≤3.5s(7”)/≤7.5s(8-12”)/≤9s(above 12”)。
4Fast line conveying speed: the fastest conveying speed of the line body: 200mm/s, the conveying speed can be set according to different product formulas.
5Fast image calculation speed: powerful image calculation processing and calculation capabilities, work does not need to be corrected, coordinate conversion function, high measurement efficiency
Stable Performance      Operation:
1Continuous operation, low failure rate, normal basic maintenance once every 6 months
2Continuous operation with high utilization rate: 7*20H
3Long service life: Imported high-precision component modules are selected to ensure the long-term stability of the equipment
4Good repeatability: the accuracy of the equipment remains unchanged after long-term operation


Model No(mm)      External Size(kgs)      Weight(kgs)Max. load    1  Power supply
ORT-ROL-6000      Roller-sifting CG AOI1320*2400*2100500kg500mm/1000mm±20mm220V(AC) 50HZ/0.8MPa
 Linear array optical system8K/16K linear array CCD
     High Definition Lens , Work-distance:330mm
      FOV:150mm ;Display resolution: 0.01mm(8K)/0.005(16K)
combined light source
 Software   Professional AOI measuring software + deep learning + Host software
