Rotary-sifting AOI ORT-ROT-500
  • Features
  • Specification
Precision Equipment      Hardware:
1Welded square tube base, post and worktable, stable, firm framework.
2The high-precision rotating platform ensures that the position of the workpiece is accurate;
3Precision Ballscrew transmission make movement fast, flexible and reliable.
4Optical grinded Glass working stage, Z-axis is calibrated to ensure travel direction vertical to glass plane so that the measuring result with high accuracy.
5The precision vibration plate ensures the consistency of the incoming material posture..
6The first one who introduced sub-pixel measurement in video measure industry. Do not need any professional operation   skills for operator, enhance measuring efficiency greatly.
Smart Software      Software
1Multiform output such as DXF,WORD, EXCEL etc. CAD drawing input and comparison function. It can directly measure and calculate straightness, roundness, position, parallelism, inclination, perpendicularity, concentricity, symmetry, and other geometric tolerances.
2Ample geometrical measurement function including drawing, label, edit, operation board measure etc., It provides measurement and drawing functions for  point, line, circle, arc, ellipse, groove, rectangle, closed curve etc.
3SPC key parameters analysis according to the data of report form, automatic calculation of Ca, Cp, Cpk, Max, Min, Range, Avg, Std etc.
4Auto tolerance output and alarm with color, sound and note, especially have product dimension tracking function.
5LED three ring lights on octant top(eight segment) + transparent parallel lights, brightness adjustable
6Fast & automatically focus function. One focusing in one second. Repeatability up to 0.002mm----0.003mm if set up the focusing time in 1-2 seconds.
7Can measure the various complex graphics including curves.
8Powerful photograph, montage and virtual measuring function.
9Lasers and probes can be added if needed, so as to complete the three-dimensional size measurement.
Ultra-fast Detection     Detection Efficiency
1Testing product: φ<13.5mm, height<2.8mm
2Fast procession to single product or feature detection, shortest CT≤2S/PC
3Fast image calculation speed: powerful image calculation processing and calculation capabilities, work does not need to be corrected, coordinate conversion function, high measurement efficiency
Stable Performance      Operation:
1Continuous operation, low failure rate, normal basic maintenance once every 6 months
2Continuous operation with high utilization rate: 7*20H
3Long service life: Imported high-precision component modules are selected to ensure the long-term stability of the equipment
4Good repeatability: the accuracy of the equipment remains unchanged after long-term operation


 Model No(mm)      External Size(kg)      Weight(kg) Max. load   Power supply
ORT-ROT-5001600*1100*1800800kg1kg220V(AC) 50HZ/0.8Mpa
Worktable(mm)      Marble Sizeφ550*320(mm)      Glass Sizeφ500
Vision system  High pixel CCD
High resolution telecentric lens
High precision laser sensor
  Accurate  image auto-measuring software
   Linear AccuracypositionaI accuracy:0.03mm        CT:2S/Pcs
 Lighting source     LED  surface ring light in five rings & octant pattern (8 phases) + transparent parallel light, all lights adjustable.
